Tension Meter

Home > Product > Tension Meter > DIGITAL TENSION METER TT990
  • Features
  • Specification
  • Applications
  • Accessories
  • Download

FEATURES

  • It employs the ‘three-roller principle’ of tension test.
  • High accuracy and high resolution.
  • Digital display with no guessing or errors.
  • Power is supplied by 4xAAA alkaline battery.
  • With 4 measurement unit for selection, N, kg, lb, g.
  • Current Value, Max. Value, Peak Value, Min Value can be displayed at the same time.
  • With 10 minutes auto power off and manual power off.
  • The Meter takes 62 tension measurements per second and displays the average of these measurements.
  • With data output, by USB cable or Bluetooth adapter.





SPECIFICATION



Tension Range

0~2.0kgf
0~2000gf
0~19.6N
0~4.4Lbf


Resolution

0.001kgf
1gf
0.01N
0.001Lbf
Accuracy ±1.5% or better
Unit kgf, gf, N, Lbf
Measuring Principle Strain gauge
Measuring Frequency 16 msec (62.5 samples/sec)
Sensing Roller Deflection of Sensing Roller (max.) 0.2mm
Overload Capacity 150% of Full Scale
Temperature Zero: less than +0.3% FS/°C
Coefficient Span: less than +0.01% FS/°C
Display Blue Back light LCD
Display Update Rate 0.5, 1.0, 2.0 or 4.0 seconds, selectable
Memory System Current Value, Max. Value,
Peak Value, Min Value
Overrange Indicator Buzzer Alarm
Power Off 10 Minutes Auto, Manual
Data Output USB, Bluetooth
Roller Material Stainless Steel (Standard)
Plastic (Optional)
Maximum Speed 2000m/min
Power Supply 4×1.5 AAA(UM-4) Battery
Operation Temperature 0~40°C
Operation Humidity <80%
Weight 400g
Size Main Unit: 149x70x30mm
Sensor: 102x81x34mm

APPLICATION

Digital Tension Meter is a hand-held device which accurately measures the running as well as static tensions of a wide variety of process materials including yarns, fibers, wires, optical fibers, etc.

ACCESORIES

DOWNLOAD
