IR Thermometer

Home > Product > IR Thermometer > INFRARED THERMOMETER DT8811
  • Features
  • Specification
  • Applications
  • Accessories
  • Download

FEATURES

 Data Hold Function
 Low Battery Indication
 ⁰C & ⁰F Selectable
 Alarm For High & Low Temperature.
 “ MAX” , “MIN” Temperature.
 Reading Hold OR Auto Power Off : Reading will Hold for 30 Seconds after releasing Trigger & after 30 Seconds
Meter will Auto Turn Off.
 Operating Temperature & Humidity : 0⁰C to 50⁰C, 10 ~ 95% RH
 Power supply: 1.5V x2 AAA Battery
 Display Size : 30 X 30 mm
 Unit Size : 138 X 102 X 45 mm
 Weight : 107 gm

SPECIFICATION

Display : LCD Color Display With Back Light.
Measuring Range : – -50⁰C – 580⁰C (-58⁰F – 1076⁰F)
Accuracy :- ( ±3⁰C) -50⁰C To 0⁰C , (±5⁰F) -58 to 32 F
0℃ TO 580℃ ±(1.5%+1℃), 32~1076℉ ±(1.5%+5℉)
Resolution :- 0.1℃(0.1℉)
Emissivity :- 0.01~1.00 adjustable (step 0.01)
Repeatability : ±0.5%~±1℃(2℉)
Response Time : Less than 500ms 8 TO 14um
Distance Spot Ratio :- 12 : 1
Laser aiming : Less than 1mW 650nm,Laser grade II

APPLICATION

IR Thermometer Measure the surface Temperature of an object. The Units Optics Sense Emitted, Reflected &
Transmitted Energy.

Accessories

Instruction Manual , 1.5V x2 AAA Battery, Carrying Pouch.
