Digital True RMS Multimeter DT603A
This is a 3⅚ 6000 Counts Digits True RMS Multimeter with Backlight. This instrument can be used to measure AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Temperature, Frequency, Diode, Continuity, Duty cycle, NCV Test and other parameters. It is an ideal tool for...
Electrical Measurement
Electronics & Signal Analysis
Aerospace
Automobile
Chemicals & Petrochemicals
Construction & Real Estate+11 more industries
₹3,186.00
Taxes included. Free shipping across India.
Not sure it’s the right instrument?Ask the Mextech team on WhatsApp, by phone or email.
Why engineers choose it
Key features
This is a 3⅚ 6000 Counts Digits True RMS Multimeter with Backlight. This instrument can be used to measure AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Temperature, Frequency, Diode, Continuity, Duty cycle, NCV Test and other parameters. It is an ideal tool for the Electricians, Engineers, Laptop & Mobiles & Electronics appliances Repairing Centre, Factories, Industries, Laboratories, Students, Household.
At a glance
- Display
- 3 ⅚ digits 6000 Count LCD Display
- APO
- After 15 Min From last key operation.
- Power Supply
- 9V Battery.
- Display Size
- 61 X 35 mm
- Weight
- 380 gms including battery.
- Low battery Indication
- Diode and Continuity test
- Data hold & Back Light
- Fuse Protection
- Operating Temperature & Humidity: 0°C to 40°C, 45% to 80% RH
- Storage Temperature & Humidity: -20°C to 60°C, 45% to 80% RH
- Unit Size 195 X 92 X 55 mm
- Accessories: Instruction Manual, Test Leads, 9V Battery, Temperature Probe.
Technical data
Specification
| Function | Ranges | Accuracy |
| AC Voltage | 6V/60V/600V/2000V | ± 1.0%, (± 3% at 2000V) |
| DC Voltage | 600mV/6V/60V/600V/2000V | ± 0.5%, (± 2% at 2000V) |
| AC Current | 6mA/60mA/600mA/20A | ± 1.5% (up to 600mA), ± 3.0% (in A Range) |
| DC Current | 600µA/6mA/60mA/600mA/20A | ± 1.0% (up to 600mA), ± 2.0% (in A Range) |
| Resistance | 600Ω/6kΩ/60kΩ/600kΩ/6mΩ/60MΩ | ± 0.8% |
| Capacitance | 100mF (Auto Range) | ± 3.0% |
| Temp. | -20℃ To 1000℃ | ± 1.5% |
| Frequency | 10mHZ | ± 2.0 % |
| Transistor, (HFE) | 0 to 1000 |
| Duty Cycle | 1% to 99% | |
| NCV | 90 – 1000V AC | |
| Diode | Yes | |
| Continuity | Yes |
Where it’s used
Applications
This is a 3⅚ 6000 Counts Digits True RMS Multimeter with Backlight. This instrument can be used to measure AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Temperature, Frequency, Diode, Continuity, Duty cycle, NCV Test and other parameters. It is an ideal tool for the Electricians, Engineers, Laptop & Mobiles & Electronics appliances Repairing Centre, Factories, Industries, Laboratories, Students, Household.
Application
Electrical Measurement
Electronics & Signal AnalysisIndustries
Aerospace
Automobile
Chemicals & Petrochemicals
Construction & Real Estate
Defence
Education
Electrical & Electronics
Energy & Power
HVAC & Facility Management
Iron & Steel
Laboratories & R&D
Petroleum, Oil & Natural Gas
Railway
Telecommunication
Transport & Infrastructure
Not sure it fits your application?
Tell us what you need to measure and we’ll recommend the right model.
Supplied with the instrument
Accessories
- Instruction Manual
- Test Leads
- 9V Battery
- Temperature Probe
Documentation
Digital True RMS Multimeter DT603A
Datasheets and manuals for this instrument, as PDF.
